Planetary or sun gear supplied as Shaft Planet Gear PN: 22560 (PN BR-00088). Sun, planet, and ring gears mesh inside the planetary gearbox to provide multi-stage reduction with shared load across multiple teeth. Tooth profile, module, hardness, and case depth must match the parent geartrain so meshing and contact patterns remain within design. Confirm tooth count, module, profile, hardness, and mounting against the OEM drawing. Replace mating gears as a set where the OEM specifies. Part No. BR-00088. For confirmation of fit, lead time, and pricing, contact our team via Add to Quote or [email protected].
⚠ System-generated illustration. This image is an AI-generated drawing and does not reflect the exact item being offered. Please contact customer support for actual product images.
