- Item: Spring Spacer, PD15 B PN: 100200
- Manufacturer: Braden (PACCAR Winch)
- Manufacturer description: Spring Spacer
- Manufacturer part no.: 100200
- Quantity on record: 6 EA
- Handal stock code: BR-00365
- Location: Handal yard, Telok Kalong, Kemaman (Malaysia)
Energy-storage component supplied as Spring Spacer, PD15 B PN: 100200 (Handal stock code BR-00365). This spring or diaphragm is sized for service in a crane brake, clutch, valve, accumulator, or pump assembly. Rate, free length, wire diameter, end configuration, and material grade must match the OEM specification so the load–deflection curve is preserved. Confirm free length, rate, wire/disc dimensions, and material grade against the OEM service drawing. Replace springs in matched sets where the OEM specifies. Handal stock code BR-00365. For confirmation of fit, lead time, and pricing, contact our team via Add to Quote or [email protected].
⚠ System-generated illustration. This image is an AI-generated drawing and does not reflect the exact item being offered. Please contact customer support for actual product images.
OEM / Specifications
- Manufacturer: Braden (PACCAR Winch)
- Product: Spring Spacer
- Series: PD15B
- Manufacturer part no.: 100200
- Nsn: 5365-01-505-4212
- Winch model: PD15B-41P065-05-01
- Line pull: 15000 lb first layer
- Outer edge: 12 scallops
Manufacturer information / datasheet:
- www.pacificmarine.net/library-of-documents/braden-winch-hydraulic/brad
- aerobasegroup.com/part-number/100200_01-505-4212
Specifications from manufacturer/distributor sources (checked 2026-10-17). Buyers should verify before use.
