Description
Item details
- Item: Spring Spacer – PN: 103147
- Manufacturer: Braden (PACCAR Winch)
- Manufacturer description: Spring Spacer
- Manufacturer part no.: 103147
- Quantity on record: 4 SET
- Handal stock code: BR-00353
- Location: Handal yard, Telok Kalong, Kemaman (Malaysia)
Spring element supplied as Spring Spacer – PN: 103147 (Handal stock code BR-00353). Used to return components to a defined rest position, hold preload on bolted joints, or transmit pressure without sliding seals, this spring or diaphragm is supplied for service in crane mechanical and hydraulic assemblies. Confirm free length, rate, wire/disc dimensions, and material grade against the OEM service drawing. Replace springs in matched sets where the OEM specifies. Handal stock code BR-00353. For confirmation of fit, lead time, and pricing, contact our team via Add to Quote or [email protected].
⚠ System-generated illustration. This image is an AI-generated drawing and does not reflect the exact item being offered. Please contact customer support for actual product images.
OEM / Specifications
- Manufacturer: Braden (PACCAR Winch)
- Product: Spring Spacer
- Manufacturer part no.: 103147
- Nsn: 5360016620694
- Cage code: 08302
- Fsc: 5360 Coil Flat Leaf and Wire Springs
Manufacturer information / datasheet:
- www.orbitnsn.com/rfq/braden-carco-gearmatic/5360016620694/103147/
- dozerwinchparts.com/103147/
- www.psifp.com/itemdetail/103147
Specifications from manufacturer/distributor sources (checked 2026-10-17). Buyers should verify before use.
Manufacturer documents
- Braden CH280 Material List (Braden)
- Braden CH280A Hydraulic Winch Material List (covers units 06089, 06090, 06091, 06109) (Braden)
- Braden CH210A Hydraulic Winch Material List (Braden)
Links go to the manufacturer or distributor publication for this part number (checked 2026-10-19). Copies are held in the Handal library and available on request. Buyers should verify fit and specifications.
